photoLab
®
6100 VIS Operation
145
ba75847e01 08/2009
4.17 Photometer information ([Info])
The following photometer information is displayed:
z Photometer designation
z Version number of the meter software/method data
z Hardware version
z Series number of the meter
z Registered user
z Hardware status (for service purposes)
z Memory status
4.18 Lamp counter
The photometer counts the operating hours of the lamp. The information on
the operating hours of the lamp is given in the Info menu.
The number quoted there corresponds to the number of operating hours.
After the lamp was exchanged (see section 5.1) you should reset the lamp
counter (see section 4.16).
The meter information and result
of the self-test are displayed and
can be printed.
<HOME>
[Info]
Info
04/16/07 9:52
Model designation:
photoLab
®
6100 VIS
Serial number: 07440001
Software/methods version: 1.30-WTW-1.60
Build: 04/03/09 11:57
Hardware version: 0-
Hardware status: FF 00000000
Lamp counter 12
System test
Filter test
Wavelength calibration
Free internal memory space
Registered user
