photoLab
®
6100 VIS Technical data
163
ba75847e01 08/2009
7.3 General meter data
Dimensions 404 x 197 x 314 mm (width x height x depth)
Weight approx. 4.5 kg (without plug-in power supply)
Housing type of
protection
IP 30
Electrical
protective class
III
Test mark CE, cETLus
Allowed
environmental
conditions
Temperature Operation: +10 °C to + 35 °C
(41 °F to 95 °F)
Storage: -25 °C to + 65 °C
(-13 °F to 268 °F)
Humidity Yearly mean:
≤ 75 %
30 days/year: 95 %
other days: 85%
Climatic class 2
Power
supply
Power pack Type: FRIWO FW 7362/12
Input: 100 - 240 V ~ / 50 - 60 Hz / 0.70 A
Output: 12 V = / 2.5 A
Length of the connection cable to the
photometer: 2.0 m
Guidelines
and norms used
EMC EC directive 2004/108/EC
EN 61326-1
EN 61000-3-2
EN 61000-3-3
FCC Class A
Instrument safety EC directive 2006/95/EC
EN 61010-1
Climatic class VDI/VDE 3540
IP protection EN 60529
