OTHER IMPORTANT SETTINGS AND ADJUSTMENTS
IN THE “SET/MENU” MODE
The following five types of settings and adjustments should be
done before enjoying audio and video sources. Note that these
settings and adjustments cannot be done without monitoring the
display information (or the information displayed on the monitor
screen).
1. CENTER MODE
2. CENTER GEQ
3. PARAMETER INIT
4. MEMORY GUARD
5. INPUT LVL TRIM
SETTING/ADJUSTMENT PROCEDURE
As described on page 9, you can perform these settings and
adjustments watching the information displayed on the monitor
screen (or superimposed over the video image). So, to use this
function, first turn the monitor on.
1. Set the PARAMETER/SET MENU switch to the SET/MENU
position on the remote control unit.
2. Select an item (title) of setting/adjustment.
3. Select any desired mode or edit parameters on the item.
In the same way, perform settings/adjustments for other items.
24
PARAMETER
SET MENU
Remote control
