iPhone/iPad Connection Manual

By connecting your iPhone, iPad or iPod touch to a compatible Electone and using the various

dedicated applications, you can expand the potential of the Electone and make it an even more

integral part of your total music life.

NOTE In this manual, iPhone and iPod touch are hereafter collectively called iPhone.

Supported Models

• ELC-02/ELCU-M02

• ELS-02/ELS-02C (including Vitalize unit)

•ELB-02

• ELS-01/ELS-01C/ELS-01X (including Type U)

•ELB-01

•DDK-7

Supported iOS Devices and iOS

Yamaha Applications for Piano & Keyboard Instruments

Refer to the following web page for information on Yamaha applications for pianos and keyboard

instruments.

http://www.yamaha.com/kbdapps/

iPhone/iPad compatibility and other related system requirements vary from application to

application. Be sure, therefore, to refer to the compatibility-related information provided on the

above web page.

Certain applications do not need to be connected to an Electone. In such a case, there is no need

to follow the instructions provided in this manual.

 Download the applications

You can download the applications from the App Store, accessible by clicking or tapping the App

Store icon in each application’s page of the website above.

Use the above-mentioned models with the latest version.

When an upgrade is required, refer to the following web page for information.

http://download.yamaha.com/

Supported iOS

devices

iPhone iPhone 4S or later

iPod touch iPod touch fifth-generation or later

iPad All iPads, except first-generation

Supported iOS

iOS 9.0 or later

For Electone Users

iPhone/iPad Connection Manual

Summary of content (17 pages)

PAGE 1
For Electone Users iPhone/iPad Connection Manual By connecting your iPhone, iPad or iPod touch to a compatible Electone and using the various dedicated applications, you can expand the potential of the Electone and make it an even more integral part of your total music life. NOTE In this manual, iPhone and iPod touch are hereafter collectively called iPhone.
PAGE 2
Contents Supported Models......................................................................................... 1 Supported iOS Devices and iOS ................................................................. 1 Yamaha Applications for Piano & Keyboard Instruments ........................ 1 NOTICE .......................................................................................................... 3 Information .........................................................................................
PAGE 3
NOTICE To prevent the iPhone/iPad from falling, note the following points: • Before moving the Electone, make sure to remove the iPhone/iPad from the music rest. • Never put anything else on the music rest together with the iPhone/iPad, such as a song booklet or another iPhone/iPad. Doing so may make the music rest unstable. • Never place the Electone with the iPhone/iPad in an unstable position.
PAGE 4
Determining the Connection Type Check the connection method of the Electone you are using with an iPhone/iPad by referring to the below matrix chart. NOTE Audio signals cannot be transferred between the Electone and the iPhone/iPad. This means that audio signals created via your keyboard performance cannot be recorded to the connected iPhone/iPad.
PAGE 5
Connection A For connection instructions, see page 8. iPad USB TO DEVICE iPhone Access point 1 USB wireless LAN adaptor Connection B Wireless LAN Wireless LAN For connection instructions, see page 12. iPad USB TO DEVICE iPhone 1 USB wireless LAN adaptor iPhone/iPad Connection Manual Wireless LAN Wireless LAN Since an iPhone/iPad cannot be connected with a network while this connection is made, functions such as e-mail and net search are restricted.
PAGE 6
Connection C For connection instructions, see page 15. iPad iPhone USB TO HOST USB (A) USB (B) 1 Connection D USB cable 2 3 Lightning to USB Camera Adapter For connection instructions, see page 15. iPad iPhone USB TO HOST USB (A) USB (B) 1 USB cable 2 3 Camera Connector* * The Camera Connector is included in the Apple iPad Camera Connection Kit. Connection E For connection instructions, see page 15.
PAGE 7
Connection F For connection instructions, see page 15. iPad iPhone USB TO HOST i -UX1 1 Connection G 2 For connection instructions, see page 15. iPad iPhone 3 MIDI OUT IN OUT MIDI IN 1 2 MIDI OUT MIDI IN MIDI OUT 4 i -MX1 Lightning to 30-pin Adapter MIDI IN Make sure that i-MX1 MIDI OUT terminal is connected to the MIDI IN terminal of the Electone, and the i-MX1 MIDI IN terminal to the MIDI OUT terminal of the Electone. Connection H For connection instructions, see page 15.
PAGE 8
Connecting the Electone to an Access Point Using a USB Wireless LAN Adaptor (Connection A)  Wireless connection of the Electone to an iPhone/iPad, via an access point using a USB wireless LAN adaptor Required devices • USB wireless LAN adaptor * *For details about wireless LAN adaptor, contact your nearest Yamaha representative or the distributor listed at the end (or beginning) of your Owner’s Manual. Or you can access the following website and contact Yamaha support at your location. http://www.yamaha.
PAGE 9
Automatic Setup by WPS If your access point supports WPS, you can easily connect the Electone to access point by WPS, without making settings, such as password input, etc. NOTE Check whether your access point supports WPS by referring to the owner’s manual for the access point you are using. 1 As illustrated, press the [WPS] button via the display of the Electone.
PAGE 10
The necessary information is automatically set, and the connection between access point and the Electone has been completed. Proceed to step 6 on page 11 to connect the access point and iPhone/ iPad. If you cannot set by WPS, follow the instructions in “Displaying the Networks in the Wireless LAN and Connecting to the Network.” Displaying the Networks in the Wireless LAN and Connecting to the Network You can connect the Electone to the network by selecting it in the wireless LAN display on the Electone.
PAGE 11
Manual Setup If you cannot find the desired network on the display because SSID broadcast was disabled or the WPS function is not installed in the access point, you will need to manually input the SSID, security and password settings for connection on the setting display of the Electone. NOTE About the confirmation and changes in the access point settings, refer to the manual of the access point.
PAGE 12
Connecting Directly Using a USB Wireless LAN Adaptor (Connection B)  Direct wireless connection of the Electone to an iPhone/iPad, using a USB wireless LAN adaptor Required device • USB wireless LAN adaptor * *For details about wireless LAN adaptor, contact your nearest Yamaha representative or the distributor listed at the end (or beginning) of your Owner’s Manual. Or you can access the following website and contact Yamaha support at your location. http://www.yamaha.
PAGE 13
7 Connect the iPhone/iPad to the Electone. 7-1 7-2 7-3 8 Call up the Wi-Fi display on your iPhone/iPad by tapping Settings > Wi-Fi. Turn ON the Wi-Fi. From the network list shown on the display, tap the Electone that you set to Access Point mode or Ad Hoc mode. If the password is required, input the password, then connect. The connection procedures are completed at step 7. Use the application on your iPhone/iPad to communicate with your Electone.
PAGE 14
Troubleshooting Problems with Wireless LAN Connections Factors such as electromagnetic interference can result in disconnection and other similar problems. In such a case, please try to resolve the problem using the following countermeasures. NOTE The term “access point” below refers to any device that can function as a router.
PAGE 15
Connecting to an iPhone/iPad Using a Cable (Connection C, D, E, F, G, H)  Connecting with MIDI terminals or a [USB TO HOST] terminal 1 Turn off the power of the Electone. Quit any open application software on your iPhone/iPad. 2 Connect your iPhone/iPad to the Electone. For the proper order, carefully follow the indicated instruction steps for each connection type. 3 Turn on the Electone. 4 The connection procedures are completed at step 3.
PAGE 16
Glossary of Terms Access point A device which acts as a base station when transmitting data by wireless LAN. Some access points are combined with modem functions. Broadband An Internet connection technology/service (such as ADSL and optical fiber) that allows for highspeed, high-volume data communication. DHCP The standard for assigning required information, including an IP address etc., automatically to a computer, whenever you connect to the Internet.
PAGE 17
About Using BSD-Licensed Software The software used by this product includes components that comply with the BSD license. The restrictions placed on users of software released under a typical BSD license are that if they redistribute such software in any form, with or without modification, they must include in the redistribution (1) a disclaimer of liability, (2) the original copyright notice and (3) a list of licensing provisions.
