User’s Manual DPharp Differential Pressure and Pressure Transmitters Manual Change No. 13-005 (1) Please refer to this manual change for the handling cautions of ATEX certification if the products include the option code /KF21 or /KS25. IM No. Model & Option code IM 01C25T02-01E EJXA with option code /KF21 or /KS25 IM 01C25R03-01E Applicable Part of this Manual Change (I) (2) Please use this manual change for the page listed below. IM No. IM 01C25T02-01E Page 6-9 Contents 6.4.
(I) • When combined with Trapezoidal or Rectangular output characteristic FISCO model IIB barrier Ui = 17.5 V, Ii = 460 mA, Pi = 5.32 W, Ci = 1.76 nF, Li = 0 µH ATEX Certification (1) Technical Data a. ATEX Intrinsically Safe Type Caution for ATEX Intrinsically safe type. Note 1. EJX series pressure transmitters with optional code /KS25 for potentially explosive atmospheres: • No. KEMA 04ATEX1116 X • Applicable Standard: EN 50014, EN 50020, EN 50284, EN50281-1-1 Note 2.
The criterion for such interconnection is that the voltage (Ui), the current (Ii) and the power (Pi), which intrinsically safe apparatus can receive, must be equal or greater than the voltage (Uo), the current (Io) and the power (Po) which can be provided by the associated apparatus (supply unit).
Electrical Data • When combined with Trapezoidal output characteristic FISCO model IIC barrier [Supply/Output circuit (terminals + and –)] Ui = 17.5 V, Ii = 380 mA, Pi = 5.32 W, Ci = 1.76 nF, Li = 0 µH [Temperature sensor circuit] Uo = 7.63 V, Io = 3.85 mA, Po = 8 mW, Co = 4.8 µF, Lo = 100 mH • When combined with Linear characteristic barrier [Supply/Output circuit (terminals + and -)] Ui = 24.0 V, Ii = 250 mA, Pi = 1.2 W, Ci = 1.76 nF, Li = 0 µH [Temperature sensor circuit] Uo = 7.63 V, Io = 3.
Supply unit I.S. values Power supply-field device: The supply unit must be certified by a Notified body as FISCO model and following trapezoidal or rectangular output characteristic is used. Po ≤ Pi, Uo ≤ Ui, Io ≤ Ii Calculation of max. allowed cable length: Ccable ≤ Co – ∑Ci – ∑Ci (Terminator) Lcable ≤ Lo – ∑Li Uo = 14...17.5 V (I.S. maximum value) Io based on spark test result or other assessment, No specification of Lo and Co is required on the certificate or label.
Note 4. Operation • Keep the “WARNING” label attached to the transmitter. WARNING: AFTER DE-ENERGIZING, DELAY 5 MINUTES BEFORE OPENING. WHEN THE AMBIENT TEMP.≥65°C, USE HEAT-RESISTING CABLES≥90°C. • Take care not to generate mechanical sparking when accessing the instrument and peripheral devices in hazardous location. Note 5.
Pi=5.32W Ci=1.76nF Li=0µH Pi=5.32W Ci=1.76nF Li=0µH Pi=1.2W Ci=1.76nF Li=0µH D ( II ) Tag plate for intrinsically safe type for EJX90A No. KEMA 06ATEX0278 X EEx ia IIB/IIC T4 Tamb.:-40(-15) to 60ºC MAX PROCESS TEMP.(Tp.):120ºC T85ºC(Tp.:80ºC), T100ºC(Tp.:100ºC), T120ºC(Tp.:120ºC) Enclosure: IP66 and IP67 FISCO Field device(IIC) FISCO Field device(IIB) Entity Parameters Ui=17.5V Ui=17.5V Ui=24V Ii=380mA Ii=460mA Ii=250mA Pi=5.32W Pi=5.32W Pi=1.2W Ci=1.76nF Ci=1.76nF Ci=1.
INDEX 1138 1139 1140 1141 1142 1143 1144 1145 1146 1147 1148 1149 1150 1151 1152 1153 1154 1155 1156 1157 1158 1318* 1319* 1320* 1321* 1322* 1323* 1324* 1325* 1326* 1327* 1328* 1329* 1330* 1331* 1332* 1333* 1334* 1335* 1336* 1337* 1338* 1339* 1340* 1341* 1342 1347* 1348* 1349* 1350* 1351* 1352* 1353* 1354* Unit mbar torr atm psi psia psig g/cm2 kg/cm2 inH2O inH2O (4°C) inH2O (68°F) mmH2O mmH2O (4°C) mmH2O (68°F) ftH2O ftH2O (4°C) ftH2O (68°F) inHg inHg (0°C) mmHg mmHg (0°C) g/s g/min g/h g/d kg/s kg/min kg
INDEX 1502* 1503* 1504* 1505* 1506* 1507* 1508* 1509* 1510* 1511* 1512* 1513* 1514* 1517* 1518* 1519* 1520* 1522* 1523* 1524* 1525* 1527* 1528* 1529* 1530* 1532* 1533* 1534* 1535* 1537* 1538* 1539* 1540* 1541 1542 1543 1544 1545 1546 1547 1548 1549 1550 1551 1552 1553 1554 1555 1556 1557 1558 1559 1560 1561 Unit Mm3/min µm3/h mm3/h km3/h Mm3/h µm3/d mm3/d km3/d Mm3/d cm3/s cm3/min cm3/h cm3/d kL kL/min kL/h kL/d Nm3/s Nm3/min Nm3/h Nm3/d Sm3/s Sm3/min Sm3/h Sm3/d NL/s NL/min NL/h NL/d SL/s SL/min SL/h SL/d
