User’s Manual CNPS7700 Series Intel Socket 1155/1156/775 CPUs Core i7 Core i5 Core i3 Core 2 Quad Core 2 Duo Pentium Dual Core Pentium D Pentium 4 Celeron D AMD Socket 754/939/940 CPUs Athlon 64 Athlon 64 X2 Athlon 64 FX Opteron Dual-Core Opteron Sempron To ensure safe and easy installation, please read the following precautions. www.ZALMAN.com V 2.
1. Precautions 1) Use and keep product away from reach of children and pets. 2) Do not ingest the Thermal Grease, and avoid its contact with skin and eyes. If contact is made with skin, wash off with water. If ingested or irritation persists, seek medical attention. 3) To prevent possible injuries, gloves must be worn while handling this product. 4) Excessive force exerted on the fan may cause damage to the fan and/ or system.
. Components 1) Common Components Cooler Thermal Grease Fan Mate 2 Fan Mate 2 Cable User’s Manual Double-Sided Tape 2) Intel Components Socket 1155 / 1156 / 775 S-Type Grips Clip Support Fixing Bolts Clip Support Nuts Washers 3) AMD Components Socket 754 / 939 / 940 L-Type Grips AMD Backplate Backplate Fixing Bolts .
. Installation Requirements 1) Space Requirements The cooler’s installation requires unobstructed space with dimensions of 136㎜(width), 136㎜(height), 70㎜(depth), and the CPU as a central reference point. Please check if components such as ODDs and PSU protrude into the required space.
. Installation 1) Intel Socket 1155 / 1156 / 775 Installation ① Install the Clip Support to the motherboard according to the socket-type. Bolt(silver) Clip Support Socket 1155 / 1156 Socket 775 M/B Washer Nut Caution Lever Slot ▶ Please make note of the Lever Slot’s direction when installing the Clip Support. ② Clear off any particles or residue from the CPU’s surface then spread a thorough layer of Thermal Grease on the CPU and the base of the cooler. .
③ Install the S-Type Grips to both sides of the Clip and fasten Bolts through the holes of the Grips onto the Clip Support. 2) AMD Sockets 754 / 939 / 940 Installation ① Install the AMD Backplate to the motherboard using Washers and Backplate Fixing Bolts. Backplate Fixing Bolt M /B Washer AMD Backplate ② Clear off any particles or residue from the CPU’s surface then spread a thorough layer of Thermal Grease on the CPU and the base of the cooler. .
③ Install the L-Type Grip to both sides of the Clip and fasten Bolts through the holes of the Grips onto the Clip Support. 6. Fan Mate 2 Installation and Usage 1) Fan Mate 2 Installation ① Connect Fan Mate 2 between the Fan Cable and the motherboard as shown in the diagram below. ② Fan Mate 2 can be installed to the side of the case using Double-Sided Tape. Double-Sided Tape M /B Fan Connector (Cooler) 2) Fan Mate 2 Operation Fan Speed Control Knob Adjust the Fan Speed Control Knob for RPM control.
