Zebra® P330i Card Printer User’s Manual 980459-001 Rev C Prelim 1
Foreword This manual contains installation and operation information for the Zebra P330i Card Printers manufactured by Zebra Technologies Corporation, Camarillo, California. Return Materials Authorization Before returning any equipment to Zebra Technologies Corporation for in-warranty or outof-warranty repair, contact Repair Administration for a Return Materials Authorization (RMA) number. Repack the equipment in the original packing material and mark the RMA number clearly on the outside.
Foreword This document contains information proprietary to Zebra Technologies Corporation. This document and the information contained within is Copyrighted by Zebra Technologies Corporation and may not be duplicated in full or in part by any person without written approval from Zebra.
Foreword EUROPE: Norway Only: This product is also designed for IT power system with phase to phase voltage 230V. Earth grounding is via the polarized, 3-wire power cord. FI: “Laite on liitettävä suojamaadoitus koskettimilla varustettuun pistorasiaan” SE: “Apparaten skall anslutas till jordat uttag” NO: “Apparatet må tilkoples jordet stikkontakt” FCC Regulations Model P330i has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
Foreword P330i Printer Model The Zebra Product Number tells a story: Here is a quick review of the Zebra Card Printer Series numbering and lettering system to help you.
Foreword Icons Throughout this manual, different icons highlight important information, as follows: Note • Indicates information that emphasizes or supplements important points of the main text. Important • Advises you of information that is essential to complete a task, or points out the importance of specific information in the text. Provides an example or scenario to demonstrate or clarify a section of text. Electrostatic Discharge Caution • Warns you of the potential for electrostatic discharge.
Foreword viii P330i User’s Manual 980459-001 Rev C
Table of Contents FCC Radiation Exposure Statement (applicable to 15.247 device only) v 1 • Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Controls, Connectors, and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 LCD Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 2 • Installation and Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 General Information .
Table of Contents Card Cleaning Cartridge. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 When to Replace the Cleaning Roller . . . . . . . . . . . . . . . . . . . . . . . . 32 How To Replace the Cleaning Roller . . . . . . . . . . . . . . . . . . . . . . . . . 32 5 • Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Print Quality Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table of Contents Appendix D • Worldwide Sales & Support . . . . . . . . . . . . . . . . . . . 55 Sales and Support Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 Website . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table of Contents xii P330i User’s Manual 980459-001 Rev C Prelim 1
1 Introduction Thank you for choosing the Zebra P330i Card Printer. This manual guides you to efficient start up and operation of your new Card Printer.Printer Features The following shows the main functional features found on your P330i Printer.
Introduction Controls, Connectors, and Indicators Controls, Connectors, and Indicators Your P330i Printer has an LCD Display Panel and a Panel Button on the front and a power connector, power switch, and interface connector(s) on the rear panel.
Introduction Controls, Connectors, and Indicators LCD Panel The LCD Panel can display the following messages: Message Mode Operational INITIALIZING Scrolling READY Fixed DOWNLOADING DATA Fixed PRINTING MONO Fixed MAG ENCODING Fixed CONTACT ENCODING Fixed PRINTING CYAN Fixed PRINTING YELLOW Fixed PRINTING MAGENTA Fixed PRINTING BLACK Fixed PRINTING OVERLAY Fixed DOWNLOADING FW Fixed CLEANING PRINTER Fixed Warnings CLEAN PRINTER Scrolling REMOVE RIBBON THEN CLOSE HEAD Scrollin
Introduction Controls, Connectors, and Indicators 4 P330i User’s Manual 980459-001 Rev C Prelim 1
2 Installation and Setup General Information This section will guide you through the installation and setup of your P330i Card Printer. This consists of the following procedures, which should be performed in the order presented.
Installation and Setup Unpacking the Printer Electric Shock Caution • Limit AC power supplied to the P330i Printer to 110 ~ 230 volts, 60 ~ 50 Hertz. Limit excess current draw to 16 amps or less, using an associated circuit breaker or other such device. Never operate the printer in a location where operator, computer, or printer can get wet. Personal injury could result.
Installation and Setup Unpacking the Printer 5. Lift the printer out of the carton by holding it with both hands. 6. Please ensure that you have a clean and nearly dust free environment for proper operation and storage of the printer. 7.
Installation and Setup Unpacking the Printer Card Cleaning Cartridge CD-ROM with Driver Wizard and User’s Manual Power Cables (2) USB Cable Cleaning Kit If any items are missing, please contact your dealer. To reorder, please refer to Appendix D of this manual. 8. Remove packing tape securing the printer’s Main Cover and Card Feeder Cover. 9.
