T3002-95910(101) INSTALLATION MANUAL BRUSHCUTTERS W-HANDLE KIT
Manual For W-HANDLE Kit 1 3 Mount the handle to the shaft tube and clamp it at your best operating position. CONNECTING SWITCH WIRES • Connect the switch wires between the engine and the main unit. Pair the wires of the same color Switch Wires 2 CONNECTING THROTTLE WIRE TO THE CARBURETOR 1. Remove the air cleaner cover. 4 PUTTING ON WAIST PAD • Wrap the waist pad around the shaft tube and the throttle wire. Waist Pad 2.
Parts List Key# Description Part Number Q'ty 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 HANDLE-L-COMP HANDLE-R-COMP LEVER-ASSY CORD(A) BLACK CORD(B) RED CABLE-COMP TUBE CLAMP SCREW BRACKET-ASSY • BRACKET • CAP-L • CAP-U • BOLT • BOLT PROTECTOR BAND T3040-14200 T3002-95400 6234-14601 T3002-95710 T3002-95720 T3040-83100 5512-73220 3260-14251 0260-00516 3583-14101 3583-14111 3583-14121 3257-14192 01252-30522 01252-30525 4050-17110 3540-93120 1 1 1 1 1 1 1 1 1 1 1 1 1 2 4 5 1 Key# Description Part Num
KOMATSU ZENOAH AMERICA INC.
