Specifications

RAVENNA
WALL
ESSENTIALS
ZEPHYRONLINE.COM
The delicate curve of a glass canopy
arching over your cooktop will add
an elegance to your everyday cooking
experience. Updated with Zephyr’s
trend-setting Black Stainless Steel, the
Ravenna combines 21st century know-
how with timeless beauty. Featuring
clear and smoke-gray glass canopy
options, as well as ACT™ technology,
ICON Touch® Controls, BriteStrip™
LED lighting and a powerful, yet quiet,
600-CFM blower.
TOP
FRONT
SIDE
10 3/8”
23
15/16”
29
15/16”, 35 3/16”
8 15/16”
16 9/16”
STANDARD
min. ducted - 23”
min. recirc. - 27 1/2”
max. - 42 1/2”
Z1C-00RV
Z1C-00RVBS
min. ducted - 41 1/2”
min. recirc. - 46”
max. - 80”
10 9/16”
13
3/4”
19
3/4”
2
5/16”
3
15/16”
3 15/16”
6”
AC In
TM
C
INTERNAL BLOWER
STANDARD
INTERNAL BLOWER with ACT™
AIRFLOW CONTROL TECHNOLOGY™*
Min. - Max. CFM
Min. - Max. Sones
200 - 600
1 - 6
is an exclusive feature built into specific Zephyr hoods which can
limit the maximum blower CFM to meet local code requirements.
*AIRFLOW CONTROL TECHNOLOGY™ (ACT™)
200 - 390
1 - 4
200 - 290
1 - 3
