A timeless and classic design, Vene-
zia’s formidable pyramid design now
includes bae lters and Zephyr’s
DCBL Suppression System® elevating
this ageless range hood to unpar-
alleled levels of performance. With
directional Bloom™ HD LED light
bulbs, Venezia’s 24-inch deep capture
area is fully illuminated with warm
halogen-caliber light, while remaining
cool to the touch. Now available with
an optional wireless remote control.
TOP
7 3/4”
4 9/16”
5 3/16”
5 1/4”
AC In
C/L
5/8”
FRONT
SIDE
STANDARD
min. ducted - 27”
min. recirc.- 31 1/2”
max.- 44”
Z1C-01VE
min. ducted - 45”
min. recirc.- 49 1/2”
max. - 80”
10 9/16”
24”
14 5/16”
29 15/16”, 35 7/8”, 41 7/8”
1 9/16”
6 7/16”
10 1/4”
TM
C
INTERNAL BLOWER
STANDARD
INTERNAL BLOWER with ACT™
AIRFLOW CONTROL TECHNOLOGY™*
Min. - Max. CFM
Min. - Max. Sones
250 - 715
0.8 - 5.8
250 - 590
0.8 - 4.5
250 - 390
0.8 - 3
250 - 290
0.8 - 1.2
*AIRFLOW CONTROL TECHNOLOGY™ (ACT™)
Optional Wireless Remote Control
is an exclusive feature built into specic Zephyr hoods which can
limit the maximum blower CFM to meet local code requirements.
VENEZIA
WALL
CORE
