Magnetic Proximity Sensors (Hall Effect)
MP1013 Sensors
Hall-effect position sensor with convenient snap-fit mounting
Description
The MP1 Series sensors are one-piece non-contact solid-state position sensors. The sensors operate through the use of Hall Effect
technology with magnetic fields generated by permanent magnets. They provide a sinking current output.
Features
Typical Applications
 Solid state reliability
 Stable output over operating temperature range
 Open collector (NPN) output can be used with bipolar or CMOS
logic circuits with suitable pull-up resistor
 South pole sensitive
 Unipolar device (MP101301, MP101302)
 Latching version available (MP101303)
 RoHS compliant
 Fastener-less design
 IP67
 Door position & interlock
 Limit switch
 Flow/speed
 Home security
 Pedal switch
Environmental Specifications
Operating / Storage Temperature (MP101301, MP101303)
-40 °C to 85 ⁰C (-40 ⁰F to 185 ⁰F)
Operating / Storage Temperature (MP101302)
-40 ⁰C to 125 °C (-40 ⁰F to 257 ⁰F)
Ingress Protection
IP67
Electrical Specifications
Operating Supply Voltage
5 to 24 VDC
Supply Current (MP101301, MP101302)
4.1 mA typ., 7.5 mA max.
Supply Current (MP101303)
2.6 mA typ., 5 mA max.
Output Current (Sink) (MP101301, MP101302)
25 mA max.
Output Current (Sink) (MP101303)
20 mA max.
Maximum Input Voltage (MP101301, MP101302)
30 VDC
Maximum Input Voltage (MP101303)
28 VDC
Maximum Reverse Voltage (MP101301, MP101302)
30 VDC
Maximum Reverse Voltage (MP101303)
None
Recommended Pull-Up Resistor
See chart
Mechanical Specifications
Housing Material
Glass-reinforced nylon plastic
Turn on / off (MP101301, MP101302)
245 Gauss / 60 Gauss
Turn on / off (MP101303)*
60 Gauss / 60 Gauss
*MP101303 is a latching sensor and releases when 60 Gauss is applied to the north pole
