Network PTZ Dome Cameras Quick Guide V1.
Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. NOTE! Before you start, connect all the needed cables and cut off the copper wires for the cables that you don't use. Please use self-adhesive waterproof tape (supplied with some products) to protect the cables. Use waterproof components to protect the network cable.
Tighten Tighten Tighten Waterproof tape Wrap the unused cables together into a bundle 3. Install the supplied waterproof components to the network cable in sequence. CAUTION! You need to mount the rubber ring onto the network cable interface first. 4. If your camera has a DC cable and you will not use it, insert the plug into the interface. DC interface Plug 5. (Optional) After the waterproof treatment is completed, put the cables into a waterproof junction box (purchased separately).
1 Packing List Contact your local dealer if the package is damaged or incomplete. The attachments may vary with models, please see the actual model for details. No. Name Qty Unit 1 Camera 1 PCS 2* Waterproof components（1） 1 Set 3* Screw components（2） 1 Set 4* Mount accessory （3） 1 Set 5 User manual 1 Set 6 Antenna 1 Set Remarks: * means optional and supplied with certain models only. (1)Including one or more waterproof components such as tape and plug.
When connecting to an external interface, use an existing connection terminal, and ensure that the cable terminal (latch or clamp) is in good condition and properly fastened. Ensure that the cable is not tense during mounting, with a proper margin reserved to avoid poor port contact or loosening caused by shock or shake. During transportation, special attention is required to protect the transparent dome cover from friction, scratch and stain, etc.
3.2 Cable Connection The appearance and tail cable may vary with device model. Power cable Reset button Network cable IP Network 4 Mount Your Camera 4.1 (Optional) Insert Micro SD Card You need to install a Micro SD card first if you want to save video on an on-board SD card. You need to open the back cover of the camera first. Before you insert or remove the Micro SD card, be sure to disconnect power and wait till the camera stops operation; otherwise, the camera or the Micro SD card may be damaged.
support the weight of the camera. Please prepare the installation tools in advance. 1. Locate the positions of the holes. Paste installation positioning stickers on the wall and align the cross center to the hole in the wall. 2. Drill holes on the wall. Use a φ6-6.5mm drill bit to drill 30mm-depth guide holes according to the positions marked by the sticker. 3. Mount the plastic rivets of self-tapping screws. Knock the plastic rivets into the guide holes and ensure that they are tightened up. 4.
5. Mount your camera onto the wall. Lead tapping screws through the guide holes in the camera base and fix them on the wall using a screwdriver. CAUTION! During the wiring process, do not hold the tail cable for weight bearing, otherwise, cable connection might be loosened. 5 Startup After you have installed the device, connect one end of the power adapter (purchased separately) to power supply, and then connect the other end to the power interface to start up the device.
6 Access Your Camera 1. Open your Web browser, enter the camera's IP address in the address bar, and then press Enter. The default IP is 192.168.1.13. 2. In the login page, enter the default username and password (admin/123456), then click Login. NOTE! DHCP is enabled by default. If a DHCP server is used in your network, your camera may be assigned an IP address, and you need to use the assigned IP address to log in. You may need to install a plug-in at your first login.
configure Wi-Fi settings. (1) Tap + in the upper right corner, and choose Add Wi-Fi Device. (2) Choose camera, and follow the on-screen instructions or voice prompts to complete device Wi-Fi configuration and adding the device. The register code is on the device body or user manual. NOTE! Before adding the camera, connect your mobile phone to a Wi-Fi network, so that the app fills in the connected Wi-Fi name automatically when configuring device Wi-Fi.
Disclaimer and Safety Warnings Copyright Statement ©2020 Zhejiang Uniview Technologies Co., Ltd. All rights reserved. No part of this manual may be copied, reproduced, translated or distributed in any form by any means without prior content in writing from Zhejiang Uniview Technologies Co., Ltd (referred to as Uniview or us hereafter). The product described in this manual may contain proprietary software owned by Uniview and its possible licensors.
Uniview reserves the right to change any information in this manual without any prior notice or indication. Due to such reasons as product version upgrade or regulatory requirement of relevant regions, this manual will be periodically updated. Disclaimer of Liability To the extent allowed by applicable law, in no event will Uniview be liable for any special, incidental, indirect, consequential damages, nor for any loss of profits, data, and documents.
Enable HTTPS/SSL: Use SSL certificate to encrypt HTTP communications and ensure data security. Enable IP address filtering: Allow access only from the specified IP addresses. Minimum port mapping: Configure your router or firewall to open a minimum set of ports to the WAN and keep only the necessary port mappings. Never set the device as the DMZ host or configure a full cone NAT.
Make sure the power supply provides a stable voltage that meets the power requirements of the device. Make sure the power supply's output power exceeds the total maximum power of all the connected devices. Verify that the device is properly installed before connecting it to power. Do not remove the seal from the device body without consulting Uniview first. Do not attempt to service the product yourself. Contact a trained professional for maintenance.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Compliance Information Statement refer to: http://en.uniview.
