Ethernet over Copper Product Guide Enabling high bandwidth without the cost of fiber construction Access for a Converging World
/3 Copper is everywhere... Ethernet loop bonding delivers high-bandwidth services without the cost of fiber construction. With more than 85% of all US businesses served by copper today, copper loop bonding is the ideal solution for optimizing OPEX. The business case works — Ethernet access has a quick ROI, with gross margins of 80% realized by incumbent and alternative carriers alike! Simple to install, fast to deploy… without costly fiber installations or infrastructure additions.
Ethernet over Copper as Frame Relay replacement The key innovation in EFM is the loop bonding of multiple copper circuits to provide increased bandwidth. By intelligently distributing traffic across multiple circuits, and using very high-efficiency hardware processing, these multiple circuits appear to the network as a single, high-bandwidth link, overcoming the limitations of individual copper circuits.
... Easy, Proven, Deployed. /5 3300 Series EtherXtend EADS 3000 Series EtherXtend EADS Fully featured, high-capacity loop bonding and multi-standard support all-in-one device using extended rate SHDSL.bis with inband OAM Fully managed and intelligent features using 802.3ah EFM standards with inband OAM over bonded extended rate SHDSL.bis ETHX 3344: 4-port SHDSL.bis ETHX 3384: 8-port SHDSL.bis ETHX 3014: 1-port SHDSL.bis ETHX 3024: 2-port SHDSL.bis ETHX 3044: 4-port SHDSL.bis n Up to 45.
EtherXtend Ethernet Access Device Product Selection Guide 3000 Series 2200 Series 2100 Series TNE SNE ENE SHDSL.bis 5.7 Mbps SHDSL.bis 5.7 Mbps DS3 45 Mbps SHDSL.bis 5.7 Mbps T1 1.544 Mbps SHDSL 2.3 Mbps E1 2.048 Mbps 4 or 8 1, 2 or 4 1 or 2 1 or 2 1, 2, 4 or 8 1, 2 or 4 1, 2, 4 or 8 Bandwidth (at max ports) Up to 45.6 Mbps Up to 22.8 Mbps Up to 90 Mbps Up to 11.4 Mbps Up to 12 Mbps Up to 9.2 Mbps Up to 16 Mbps Loop Bonding 802.3ah EFM N2N 802.
/7 Ethernet Aggregation MALC-MSAP MALC-EFM-SHDSL-24 MALC-EFM-T1 / E1-24 MALC-EFM-SHDSL-24 NTP MALC-EFM-SHDSL-24 NTWC n 802.1ad Q in Q transparent LAN support n Bridging and routing support on all ports n 802.3ah (EFM) compliance with 802.3ah OAM n N2N loop bonding support with 802.
Aggregation Platforms Line Card MALC-EFMSHDSL-24 MALC-EFMT1 / E1-24 Access Interface SHDSL.bis 5.7 Mbps Loop Bonding 8800 /8620 DSLAM IPD 4000 / 12000 DSLAM 8986-B1-000 ESIM5700-48 SIM2000-24 TIM1500-24 EIM2000-24 T1 / E1 SHDSL.bis 5.7Mbps SHDSL.bis 5.7 Mbps SHDSL 2.3 Mbps T1 E1 802.3ah, N2N N2N 802.3ah N2N N2N N2N N2N 24 24 24 48 24 24 24 319: 8 / 192 719: 16 / 384 723: 20 / 480 CLI, Web, SNMP ZMS 319: 7 / 192 719: 17 / 384 723: 19 / 480 CLI, Web, SNMP ZMS QoS 802.
Serving Customer Needs Zhone Delivers Higher Bandwidth to Netmedia “ Using Zhone’s Ethernet over Copper solutions with both E1 and SHDSL lines has enabled delivery of higher bandwidth Ethernet business services in Finland over existing copper lines, thereby creating new and profitable Ethernet business services by re-using existing plant.
