R 24 C 3 MANUEL D'UTILISATION 2 2 GEBRAUCHSANWEISUNG 14 6 BRUGSANVISNING 26 5 INSTRUCCIONES DE USO 38 4 OPERATING MANUAL 50 > ISTRUZIONI D’USO 62 u BRUKSANVISNING 74 1 GEBRUIKSAANWIJZING 86
Dear Sir, Madam, Congratulations on your purchase of this heater. You have purchased a quality product, which will serve you for many years to come. This, of course, provided you use the heater correctly. Please read these Directions for Use first, to ensure the maximum lifetime for your heater. This appliance comes with a 48-month manufacturer’s warranty on all defects in material or workmanship. We wish you much warmth and comfort from your heater. Yours sincerely, PVG Holding b.v.
GENERAL DIRECTIONS FOR USE MAIN COMPONENTS Below you will find the main steps to be taken for using your heater. For more details, please refer to OFF - button Knurled wick the MANUAL (pages 53 ff.). adjustment knob 1 Remove all packaging materials (refer to Section A, Fig. A). 2 Fill the removable tank and wait 30 minutes before you Ignition button Combustion ignite the heater (refer to Section B, Fig. I).
WHAT YOU NEED TO KNOW IN ADVANCE VENTILATE SUFFICIENTLY This heater is equipped with an air quality control system . When there is insufficient ventilation in the room or when the heater is being used in a room which is too small, the heater will shut off automatically. For comfortable and safe heating ensure that there is sufficient ventilation. Note: To avoid unexpected shut off, we recommend to put a door or window ajar when the heater is operating.
MANUAL A A INSTALLING THE HEATER Carefully remove your heater from the box and check the contents. In addition to the heater you also need to have: a transportation cap these directions for use B manual fuel pump Keep the box and the packaging materials (Fig. A) for storage and/or transportation. Remove the other packaging materials: C Release the right side of the grill from the two slots by pulling the right side of the grill to the left and then pull it forward (Fig. B).
I (cap pointing upwards, handle on floor (Fig. I) and screw off the fuel cap. Fill the removable tank using a fuel pump (refer to fuel pump operation instructions.) Make sure that it is in a higher position than the removable tank (Fig. I). Insert the ribbed hose into the opening of the removable tank. Check the removable tank fuel gauge while filling the tank (Fig. J). Stop filling once the gauge indicates that the tank is full.
F ☞ After having ignited the heater, always check whether the combustion chamber is level, by sliding it slightly to the left and the right by its handle (Fig. F). This should be a smooth movement. If the combustion chamber is not level, this will cause smoke and soot to develop. D BURNING OF THE HEATER After you have ignited the heater, it will take 10 to 15 minutes before you can check whether the heater is burning well.
IRREGULAR FLAME AND/OR SOOT AND/OR SMELLS The combustion chamber has not been positioned correctly. Use the handle to put it level, until you can easily slide it slightly to the left and to the right and the chamber is level. You are using fuel which is past its ‘use by’ date. Start every heating season with fresh fuel. You are using the incorrect type of fuel. Refer to THE RIGHT FUEL (See Section ’What you need to know in advance’). Dust has gathered in the lower part of the heater.
1. THE BATTERIES You may replace the batteries yourself. Do not dispose of old batteries along with the other domestic waste. Follow the locally applicable regulations regarding the disposal of domestic chemical waste. 2. THE IGNITION COIL The ignition coil will have a longer life, if you ignite the heater in the correct manner. Replace the batteries in time and take care not to push in the ignition button with too much force.
I O TRANSPORTATION Take the following measures to avoid fuel leakage during the transportation of the heater: Let the heater cool down. Remove the removable tank from the heater and remove the fuel filter (Fig. O). Some drops may leak from the filter; keep a cloth at hand. Store the fuel filter and the removable tank outside the heater. P Place the transportation cap into the position of the fuel filter (Fig. P). Press it tight.
The warranty will not apply to parts that are subject to normal wear, such as the batteries, the ignition coil, the wick and the manual fuel pump. The warranty will only apply, when you present the original, dated proof of purchase, provided no changes have been made to it. The warranty will not apply to damages caused by actions not in compliance with the Directions for Use, neglect, and the use of an incorrect type of fuel, or fuel past its use-by date. The use of incorrect fuel can even be dangerous*.
20 cm 50 cm 150 cm 1 REPLACEMENT OF THE WICK 50 cm 2 L ENSURE THAT THE HEATER IS OFF AND COMPLETELY COOL BEFORE STARTING TO REPLACE THE WICK. Open the lid and remove the removable tank. Remove the batteries from the battery holder. 3 4 Open the front grill. Remove the combustion chamber from the heater. Close the grill. Pull the knurled wick adjustment knob off the heater. Unscrew the three cabinet screws on the back and sides 5a 5b of the heater.
12a 12b Install the wick to the wick sleeve according to the allowed direction engraved on the wick sleeve. Install the wick sleeve (with wick) to the primary air tube. And then turn the wick sleeve clockwise to set in the handle arm. 13a 13b Install the bracket. Then tighten the screw which is holding the stem. Put the wick holder chassis back into position. Screw the four wing nuts hand tight. 100 cm 14b 14a 20 cm Place the knurled wick adjustment knob on the wick mechanism.
✗ ✓ 1-3 cm.
