Dimensional Data (inches and [ mm ]) are Subject to Manufacturing Tolerances and Change Without Notice
SPECIFICATION SHEET
TAG _______
* Regularly furnished unless otherwise specified.
Zurn Industries, LLC | Light Commerical Plumbing Products
1801 Pittsburgh Avenue, Erie, PA U.S.A. 16502 · Ph. 855-663-9876, Fax 814-454-7929
In Canada
| Zurn Industries Limited
3544 Nashua Drive, Mississauga, Ontario L4V 1L2 · Ph. 905-405-8272, Fax 905-405-1292
www.zur n.com
Rev. J
Date: 8/14/2017
C.N. No. 137560
Prod. | Dwg. No. GT2702
GT2702 Grease Interceptor
Recommended for removing and retaining grease from wastewater in kitchen and restaurant areas where food is prepared. Con-
structed of non-corrosive polyethelene, the interceptor handles continuous temperatures to 212° F. Trap is furnished with NPT
connections, removable flow diffusing baffles and external vented flow control device.
Product
___GT2702-04
'A' & 'B'
Inlet/Outlet
2 [51] FEMALE NPT
Flow Rate
G.P.M.
[L.P.M.]
4 [15]
7 [26]
10 [38]
15 [57]
20 [76]
25 [95]
Grease
Capacity
Lbs. [kg]
10 [254]
C
9-1/2 [241]
D
2 [51]
EF
15 [381]
Dimensions In Inches [mm]
11 [279]
3-1/4 [83]
20 [508]
3-1/2 [89]
23 [584]
23 [584]
29 [737]
35 [132]
50 [189]
4 [102] 32-1/2 [826]
4 [102]
37 [940]
___GT2702-07
___GT2702-10
___GT2702-15
___GT2702-20
___GT2702-25
___GT2702-35
___GT2702-50
2 [51] FEMALE NPT
2 [51] FEMALE NPT
2 [51] FEMALE NPT
2 [51] FEMALE NPT
3 [76] FEMALE NPT
3 [76] FEMALE NPT
3 [76] FEMALE NPT
8 [4]
14 [6]
20 [9]
30 [14]
40 [18]
50 [23]
70 [32]
100 [45]
Liquid Holding
Capacity
Gal. [L]
1.5 [5.7]
4.6 [17.4]
6 [22.7]
10.2 [38.6]
15 [56.8]
20.8 [78.7]
26.1 [98.8]
35.5 [134.4]
G
12 [305]
13 [330]
14 [356]
17 [432]
18 [457]
18 [457]
4 [102]
3-1/2 [89]
3-1/2 [89]
2 [51]
3-1/4 [83]
3-1/2 [89]
4 [102]
4 [102]
4 [102]
3-1/2 [89]
3-1/2 [89]
32-1/2 [826]
14-1/2 [368]
14-1/2 [368]
19-1/2 [495]
19-1/2 [495]
19-1/2 [495]
22 [559]
25 [635]
___ 6 [152] Extension
GT2702
Polyethylene Grease Interceptor
75 [284]
5-3/4 [146]
44-1/4 [1124]
___GT2702-75
3 [76] FEMALE NPT 150 [68] 61.8 [234] 25 [635] 5-3/4 [146]
25 [635]
Sizes 4 - 50
