Exposed Z6203 Model
Metroflush Piston Operated Flush Valve
For 3/4" Urinal Valves
Suffix Options (Check/Specify Appropriate Options)
_____ -L 1"[25] Metal Push Button
_____ -L3 3"[76] Metal Push Button
_____ -VC Vandal Resistant Stop Cover
_____ -XYV Less Vacuum Breaker
_____ -YB Sweat Solder Kit
_____ -YC Cast Wall Flange
_____ -YJ Split Ring Pipe Support
_____ -YK Solid Ring Pipe Support
_____ Other
This space is for Architectural/engineering Approval
Flow Options
-EWS 0.5 Gallons Per Flush
-WS1 1.0 Gal. Low Consumption Flush
-FF 3.0 Gal. Full Flush
Standard Flush 1.5 Gallons Per Flush
Rev. D Date: 1/31/07
Dwg. No. 61397 Product No. Z6203
ENGINEERING SPECIFICATION: ZURN Z6203 Metroflush Pis-
ton Operated Exposed Urinal Flush Valve- The Metroflush is
an exposed, quiet piston type, chrome plated flushometer valve
with polished exterior. Complete with Zurn MetroVantage chloram-
ine resistant piston with a clog resistant filtered by-pass. The
valve is ADA compliant with a non-hold open and no-leak handle
feature, high back pressure vacuum breaker, one piece hex cou-
pling nut, adjustable tailpiece, spud coupling and flange for top
spud connection. Control stop has internal siphon-guard protec-
tion. Internal seals are made of chloramine resistant materials.
