Specification Sheet

TAG _______
AquaSpec
®
is a registered trademark of Zurn Industries, LLC
©2010 Zurn Industries, LLC
ZURN INDUSTRIES, LLC
♦♦
♦♦
♦ COMMERCIAL BRASS OPERATION
♦♦
♦♦
♦ 2640 SOUTH WORK STREET
♦♦
♦♦
♦ FALCONER NY 14733
Phone: [phone]
♦♦
♦♦
♦ Fax: [phone]
♦♦
♦♦
♦ www.zurn.com
In Canada: ZURN INDUSTRIES LIMITED
♦♦
♦♦
♦ 3544 Nashua Drive
♦♦
♦♦
♦ Mississauga, Ontario L4V1L2
♦♦
♦♦
♦ Phone: [phone] Fax: [phone]
Note:
Dimesions subject to manufacturing
tolerances. Other pipe and fittings not
furnished by manufacturer.
_____________________________
SIERRA LEAD-FREE FAUCET
Z7440-XL
Rev. A Date: 4/30/10 C.N. No. 126130
Dwg. No. 93358 Product No. Z7440-XL
Engineering Specifications: Zurn AquaSpec
®
Sierra Lead-Free Faucet Z7440-XL
Polished chrome plated 4”[102mm] centerset single control lavatory faucet with 5”
[127mm] integral spout, a ceramic disc cartridge and a temperature limit stop. Unit is
furnished with 2.2 GPM [8.3L] aerator (complying with ANSI A112.18.1M Standard for
flow), an ADA compliant lever handle, 3/8” stainless steel flex hose 18” [457mm] in
length with 3/8” female compression fitting.
Zurn Lead Compliant* “XL” products are a line of durable, high quality brass faucets and
fixtures that are designed and manufactured to comply with state laws and local codes
that mandate lead content levels. Zurn “XL” products are manufactured with *not more
than 0.25% lead content when used with respect to wetted surfaces of pipes and pipe
fittings, plumbing fitting and fixtures: California Health & Safety Code § 116875;
Vermont 9 VCA § 2470h
OPTIONS (Check/specify appropriate options)
__ - CST Copper Supply Tubes w/ 1/2” IPS Fitting
__ - FC 0.5 GPM [1.9L] Vandal Resistant Aerator
__ - LA 2.2 GPM [8.3L] Laminar Flow Aerator
__ - SO 1.0 GPM Spray Outlet
__ - VP 2.2 GPM [8.3L] Vandal Resistant Aerator
__ - VP1.5 1.5 GPM [5.7 L] Vandal Resistant Aerator
FLOW RATE
2.2 GPM (8.3 LPM) @ 80 PSI
Model No.
Z7440-XL
Z7441-XL
Z7442-XL
Z7443-XL
Lever
Handle
X
X
X
X
No
Pop-Up
Hole
X
X
With
Lift Rod
Only
X
With
Metal
Pop-Up
X
With
Grid
Strainer
X
STANDARDS
Lever handle models meet or exceed
ANSI A117.1M Handicap specifications.
