Note:
Dimesions subject to manufacturing
tolerances. Other pipe and fittings not
furnished by manufacturer.
_________________________________________________
SIERRA FAUCET
Z7440-XL
Rev. C Date: 3/28/11 C.N. No. 127536
Dwg. No. 93358 Product No. Z7440-XL
Engineering Specifications: Zurn AquaSpec
®
Sierra Faucet Z7440-XL
Polished chrome plated 4”[102mm] centerset single control lavatory faucet with 5” [127mm]
integral spout, a ceramic disc cartridge and a temperature limit stop. Unit is furnished with
2.2 GPM [8.3L] aerator (complying with ANSI A112.18.1M Standard for flow), an ADA
compliant lever handle, 3/8” stainless steel flex hose 18” [457mm] in length with 3/8” female
compression fitting.
Zurn Lead Compliant* “XL” products are a line of durable, high quality brass faucets and fixtures
that are designed and manufactured to comply with state laws and local codes that mandate
lead content levels. Zurn “XL” products are manufactured with *not more than 0.25% lead
content when used with respect to wetted surfaces of pipes and pipe fittings, plumbing fitting
and fixtures: California Health & Safety Code § 116875; Vermont 9 VCA § 2470h.
OPTIONS (Check/specify appropriate options)
__ - CST Copper Supply Tubes w/ 1/2” IPS Fitting
__ - FC 0.5 GPM [1.9L] Vandal Resistant Aerator
__ - LA 2.2 GPM [8.3L] Laminar Flow Aerator
__ - SO 1.0 GPM [3.8L] Spray Outlet
__ - VP 2.2 GPM [8.3L] Vandal Resistant Aerator
__ - VP1.5 1.5 GPM [5.7 L] Vandal Resistant Aerator
___ -SO.35 0.35 GPM [1.3 L] Pressure Compensating Spray Outlet
___ -SOVP.35 0.35 GPM [1.3 L] Vandal-Resistant Pressure Compensating Spray Outlet
Model No.
Z7440-XL
Z7441-XL
Z7442-XL
Z7443-XL
Lever
Handle
X
X
X
X
No
Pop-Up
Hole
X
X
With
Lift Rod
Only
X
With
Metal
Pop-Up
X
With
Grid
Strainer
X
STANDARDS
Lever handle models meet or exceed
ANSI A117.1M Handicap specifications.
FLOW RATE
2.2 GPM (8.3 LPM) @ 80 PSI
