Dimension GS-3012 Gigabit Ethernet Switch
Access Control 17-5
Figure 17-5 Access Control: Logins
The following table describes the labels in this screen.
Table 17-5 Access Control: Logins
LABEL DESCRIPTION
Administrator
This is the default administrator account with the “admin” user name. You cannot change the default administrator
user name. Only the administrator has read/write access.
Old Password Type the existing system password ("1234" is the default password when shipped).
New Password Enter your new system password.
Retype to confirm Retype your new system password for confirmation
Edit Logins
You may configure passwords for up to four users. These people have read-only access.
User Name Set a user name (up to 32 characters long).
Password Enter your new system password.
Retype to confirm Retype your new system password for confirmation
Apply Click Apply to save your changes back to the switch.
Cancel Click Cancel to begin configuring this screen afresh.
17.4 SSH Overview
