Dimension GS-3012 Gigabit Ethernet Switch
28-22 Introduction to CLI
Table 28-5 Command Summary: Interface
COMMAND DESCRIPTION
<wt1> <wt2> ... <wt8>
Sets the interface to use WRR
queuing. A weight value of one to
eight is given to each variable
from wt 1 to wt 8.
egress set <port-list>
Sets the outgoing traffic port list
for a port-based VLAN.
pvid <1-4094>
The default PVID is VLAN 1 for
all ports. Sets a PVID in the
range 1 to 4094 for the specified
interface.
ingress-check
Enables the device to discard
incoming frames for VLANs that
are not included in a port
member set.
gvrp
Enables this function to permit
VLAN groups beyond the local
switch.
frame-type <all|tagged>
Choose to accept both tagged
and untagged incoming frames
or just tagged incoming frames
on a port.
name <port-name-string>
Sets a name for your interface.
Enter a descriptive name (up to
nine printable ASCII characters).
vlan-trunking
Enables VLAN Trunking on ports
connected to other switches or
routers (but not ports directly
connected to end users) to allow
frames belonging to unknown
VLAN groups to pass through the
switch.
flow-control
Enables interface flow control.
Flow control regulates
transmissions to match the
bandwidth of the receiving port.
qos priority <0 .. 7>
Sets the quality of service priority
for an interface.
mirror
Enables port mirroring in the
interface.
mirror dir <ingress|egress|both>
Enables port mirroring for
incoming, outgoing or both
incoming and outgoing traffic.
Port mirroring copies traffic from
one or all ports to another or all
ports for external analysis.
