Dimension GS-3012 Gigabit Ethernet Switch
IEEE 802.1Q Tagged VLAN Commands 30-7
30.5.5 Delete VLAN ID
Syntax:
no vlan <vlan-id>
where
<vlan-id>
=
The VLAN ID [1 – 4094].
This command deletes the specified VLAN ID entry from the static VLAN table. The following example deletes
entry 2 in the static VLAN table.
Figure 30-9 no vlan Command Example
30.6 Enable VLAN
Syntax:
vlan <vlan-id>
This command enables the specified VLAN ID in the SVLAN (Static VLAN) table.
30.7 Disable VLAN
Syntax:
vlan <vlan-id>
inactive
This command disables the specified VLAN ID in the SVLAN (Static VLAN) table.
30.8 Show VLAN Setting
Syntax:
show vlan
This command shows the IEEE 802.1Q Tagged SVLAN (Static VLAN) table.
An example is shown next.
For the
AdCtl section of the last column, “-“ is a port set to normal, “x” is a forbidden port and “F” is a fixed port.
GS-3012 (config)# no vlan 2
