Dimension GS-3012 Gigabit Ethernet Switch
Basic Setting 6-1
This chapter describes how to configure the System Info, General Setup, Switch Setup, IP Setup
and Port Setup screens.
6.1 Introducing the Basic Setting Screens
The System Info screen displays general switch information (such as firmware version number) and hardware
polling information (such as fan speeds). The General Setup screen allows you to configure general switch
identification information. The General Setup screen also allows you to set the system time manually or get the
current time and date from an external server when you turn on your switch. The real time is then displayed in the
switch logs. The Switch Setup screen allows you to set up and configure global switch features. The IP Setup
screen allows you to configure a switch IP address, subnet mask and DNS (domain name server) for management
purposes.
6.2 System Information
In the navigation panel, click Basic Setting and then System Info to display the screen as shown. You can check
the firmware version number and monitor the switch temperature, fan speeds and voltage in this screen.
Chapter 6
Basic
Setting
